KPC132E
| Pick up Element | 1/3″ H.R. color CCD image sensor |
| Number of Pixel |
771(H) x 492(V) |
| Resolution | 520 TV Lines |
| Min. Illumination | 0.1 Lux / F2.0 |
| S/N Ratio | More than 48dB (AGC off) |
| Electronic Shutter | 1/60 (1/50) to / 100,000 sec. |
| Lens | f3.6mm / F2.0 |
| Lens Angle | 92° |
| IRIS Mode | AES |
| White Balance | ATW |
| Video Output | 1.0 Vp-p composite, 75? |
| Power Source (±10%) | DC12V |
| Current Consumption | 70 mA |
| Dimensions (mm)** | 100(O) × 60(H) |
| Net Weight (g) | 78.5 |
| Gross Weight (g) | 158 |
