Pick up Element |
1/3" color CCD image sensor |
|
Number of Pixels |
512(H) x 492(V) (NTSC) / 512(H) x 582(V) (PAL) |
|
Resolution |
Standard |
|
Minimum illumination |
0.05 Lux / F2.0, 0Lux (IR ON) |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
F3.6mm / F2.0 |
|
Lens Angle |
92.6° |
|
IRIS Mode |
AES |
|
Gain Control |
Auto |
|
White Balance |
ATW |
|
Video Output |
1.0 Vp-p composite, 75Ω |
|
Power Source (±10%) |
DC 12V |
|
Current Consumption (±10%) |
70mA |
|
Dimensions (mm)** |
100(O) x 60(H) |
|
Net Weight (g) |
78.5 |
|
Gross Weight (g) |
158 |
