Pick-up Element |
1/3″ H.R. Color CCD image sensor with SONY Effio DSP |
|
Number of Pixels |
771(H) x 492(V) / 753(H) x 582(V) |
|
Min. illunation |
0.05 Lux; 0 Lux (IR on) |
|
Resolution |
Super High Resolution |
|
IR LED |
35 units |
|
IR Effective Distance |
Up to 25 meters |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000sec. |
|
Lens>/td> |
f3.8mm / F1.5 | f6.0mm / F1.4 |
|
84.5° |
54° |
|
Color Rolling Suppress |
Supported |
|
White Balance |
ATW |
|
AGC |
Auto |
|
IRIS Mode |
AES |
|
IP Rating |
IP67 |
|
Video output |
1.0 Vp-p composite, 75? |
|
Startup Temperature |
0°C ~40°C |
|
Operating Temerature |
-20°C~40°C |
|
Power Source(±10%) |
DC12V |
|
Current Consumption(±10%) |
70mA(IR off) | 400mA(IR on) |
