Pick up Element |
1/3″ color CCD image sensor |
|
Number of Pixel |
976(H) x 494(V) / 976(H) x 582(V) |
|
Resolution |
700TVL |
|
Min. Illumination |
0.1 Lux/ F2,0,0 Lux(IR ON) |
|
IR LED |
35 Units |
|
IR Effective Range |
25 Meters |
|
S/N Ratio |
More than 48dB (AGC off) |
|
Electronic Shutter |
1/60 (1/50) to 1/100,000 sec. |
|
Lens |
f3.6mm / F2.0 |
|
Lens Angle |
(horizontal) 76.3°/ (Vertical) 56.2°/ (Diagonal) 98.3° |
|
Iris Mode |
AES |
|
White Balance |
ATW |
|
Video Output |
1.0 Vp-p composite, 75? |
|
Power Source (±10%) |
DC 12V |
|
Current Consumption (±10%) |
70mA (IR OFF), 400mA (IR ON) |
|
Gross Weight(g) |
430 |
|
Dimensions (mm)** |
142(H) x 75(?) |
|
IP Rating |
IP67 |
